| Item |
Specification |
| Structure |
Carbon Steel with All Inside Seams Fully Welded |
| Standard Dimensions |
20 yd., 25 yd., 30 yd., 40 yd. |
| Walls |
3/16" Carbon Steel |
| Front Wall |
3/16" A-36 |
| Door |
3/16" A-36 with 3" sq. Tubing Frame |
| Wall Supports |
Formed Chennel, 2 per Side with an Optional 3rd in the Middle |
| Floor |
3/16" to 1/4" Plate with 3"- 4.1 Channel at 16" Intervals |
| Bottom Rails |
6 x 2 x 3/16" or Optional 6 x 2 x 1/4" |
| Door Seal |
T-Extruded Neoprene Gasket with 6 Point Chain System with Optional Mechanical Latching System |
| Testing |
Containers tested to Maximum Capacity
|
| Roof Options |
10 G Plate Roof with Tubing Sub-Frame, Sliding Over and Under, Side Hinge, Side Sliding, All available in Water Tight |
| Other Options |
Tarp |
| |
Special Order Sizes Available |
